3/4/5/6axle Construction-Grade Rear Dump Best-Selling Semi- Trailer Dump Transport Truck Trailers Rear-Tipping Dump Trailer

Introduction

PRODUCT DESCRIPTION

Basic Info.

Name: 3/4/5/6axle Construction-Grade Rear Dump Best-Selling Semi- Trailer Dump Transport Truck Trailers Rear-Tipping Dump Trailer
SKU: 0

Model NO.

CLV9500DST

Type

Semi-Trailer

Load Capacity

80T

Certification

ECE, GCC, CE, ISO9001, DOT, CCC, ISO/TS16949

Wheel Base

8000-9000mm

Tread

2240mm

Grade

Heavy Duty

Types of Suspension Systems

Leaf Spring Suspension

Shape

Van-type

Axle Number

3/4/5/6

Tire Number

12/16/20/24

Self-dumping

ABS Anti-lock Braking System

Material

Steel

Condition

New

Cylinder

Hyva Brand Hydraulic Cylinder

Axle Brand

BPW/Fuwa/Zy or Others

Axle Model

13t/16t/20t/25t

Suspension

Mechanical/Air Bag/Bogie Type

Tire

11r22.5/12r22.5/11.00r20/12.00r20/315-85r22.5

King Pin

2.0/3.5 Inches, Bolt in/ Welding

Landing Gear

Jost Brand Linkage/Single Action 28t

Payload

60t--120t

Volume

32/40/45 Cube Meters, Customization

Color

Customizable

Curb Weight

16200kg

Gross Mass

96000kg

Transport Way

Container Loading or Waxing

Function

Sand Transporting

Light

LED 8 Side Lights and 2 Rear Lights 2 Width Lamp

Transport Package

Bulk Ship/Roro Vessel

Specification

10500*2650*3700 (mm) (Customized Sizes)

Trademark

LUCKIN VEHICLE

Origin

China Qingdao

HS Code

871639900

Production Capacity

5000 Units Per Year

Product Description

Factory Direct Sales Low Price Mining 3 4 Axle 36 Cubic Meters 50 60 80 Tons U-Shaped Rear Dump Semi Trailer Dumper Transport Tipper Tipping Truck Trailer

We have a complete vehicle production line, which can meet customers' competitive price or customization needs for different semi-trailer models. We look forward to your visit and exchange in our factory.

About dump semi-trailer, we have many years of design experience and reliable after-sales service.
We treat every customer's order from beginning to end,
For dump trucks, we have different tonnage and different axle numbers for customers to choose and customize

U Shape 80T 45cbm Rear Dump Semi Trailer for Sale is becoming very popular in transporting coal, ore, sand, building materials and other bulk and unpacked goods in developing countries, especially in construction and mining fields. As top professional manufacturer and supplier of all kinds of semi-trailers, Luckin Vehicle offer you nice quality U Shape 60T Rear Dump Semi Trailer for Sale in extremely reasonable prices among the market.

Jiumeng Vehicle supply 30/40/45/50/55CBM 3/4/5/6 Axles Rear Tipper Dump Semi Trailer, which is normally used to transport unpacked and bulk goods, such as coal, ore, sand and construction materials and etc. We support designing and production according to customers' different needs, such as sizes, axles, suspensions, box types and capacity.

Type:
Axles:	2 axle	3 axle	4 axle
Nominal length (Version):	8.2m (Short)	9.2 m (Normal)	10.2m (Long)
Nominal volume (outer tailgate):	26- 32 m³	30 -36m³	33 - 40 m³
Nominal volume (inner tailgate):	25 - 31 m³	29 - 35 m³	32 - 39 m³
Side wall height:	1,400 - 1,700 mm	1,400 - 1,700 mm	1,400 - 1,700 mm

Specifacition

Tare weight	according to requirements
Size	according to requirements
Payload	40T-80T
Main beam	Heavy duty and extra durability designed I beam; opting for high tensile steel Q345B , welded by automatic submerged-Arc processes. Top flange 14mm,width140mm;Middle Flange 8mm height 500mm;bottom flange16mm,width140mm ;
Side beam	Designed according to the load weight of the trailer
Cross member	Designed according to the load weight of the trailer
Floor	Thickness 8 /10 mm
Side wall	Thickness 6/8 mm
Cylinder	HYVA brand
Axle	3 axle FUWA brand 13T /16T
Suspension	American type suspension
Leaf spring	10pcs13mm90mm
Tire	12R22.5 12+1pcs
Wheel rim	9.0-22.5 12+1pcs
Kingpin	2" bolt-in king pin
Landing gear	two-speed, manual operating ,heavy duty landing gear 28T
Twist lock	no
Braking system	WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks
ABS	4S/2M
Light	LED 8 side lights and 2 rear lights 2 width lamp
Painting	Complete chassis sand blasting to clean rust ,1coat of anticorrosive prime,2coats of final paint
Accessories	One standard tool box,one spare tire carrier,one crank,one shaft head wrench,four side light,two rear light
Date of delivery	5 workdays after we received 30% of contract value T/T down payment.

Suspention - Anti-Tire Abrasion
Specially designed anti-Tire abrasion suspension system prevent tire deflection after loading and avoids tires to the maximum extent worn out. and easy to disassemble and maintain

Brake System: T30/30 Spring brakechamber. WABCO valve,ABS/EBS system optional. dual line brake pipe.

Suspension:Multiple thickened high-strength steel leaf springs,Germany Type or American Type Mechanical and Air bag suspension can be choose.

How does a tipping trailer work?

Tipping trailers are intended primarily for the carriage of loose loads such as sand and gravel and can tip their load bodies through a large angle such that the load then slides out the back. Unlike Tiltbeds, Tipping trailers keep all their wheels on the ground during discharge.

Q1. Are you a manufacturer?
Yes, we have been in special vehicle manufacturing and marketing for over 20 years.

Q2. What markets do your vehicle export to?
South-East Asia, Africa, Oceanica, Middle East countries etc.

Q3. What information should I let you know if I want to get a quotation?
Please let us know your purpose, road condition, cargo type, tons of your cargo, dimensions of the trailer, quantity etc. The more info you provide, the more accurate model and the price you will get.

Q4. Is it available to print our own brand on the vehicle?
Of course we could support OEM and ODM services .

Q5. How can I get the price of your vehicle?
You could contact with our customer service and drop messages , we will reply you upon we got it within 24 hours .
